17" X 60" CLAUSING COLCHESTER ENGINE LATHE

17" X 60" CLAUSING COLCHESTER ENGINE LATHE

PRICE:  Loaded on Truck, Our Warehouse, York, PA …… $1,950.00 AS IS

HMC Stock # 25014-P

Machine Serial No.: 7/0018/04298

Machine Model No.: 17"

New Date: Unknown

Swing Over Bed: 17-1/4"

Swing Over Cross Slide: 10-1/2"

Distance Between Centers: 60"

Hole Thru Spindle: 3-1/16"

Spindle Nose: D1-8 Camlock

(16) Spindle Speeds: 20 to 1600 RPM

(38) Standard Threads: 2 to 72 TPI

(40) Metric Threads: .4 to 14 MM

Longitudinal Feeds: .002" to .032" Per Rev.

Cross Feeds: .001" to .016" Per Rev.

Tailstock Diameter: 2-15/16"

Tailstock Taper: #5 Morse

Tailstock Spindle Travel: 5-1/2"

Condition: Test run April of 2025. Headstock is functional but loud. Internal drive clutch in poor condition. Technically functional but will give out sooner rather than later. The additional functions of the machine were not tested and remain unknown. The oil was drained from the machine and headstock and was in very poor condition. Way wear and various spots of surface rust are present.

Overall Size: 140" LR x 48" FB x 55" High
